The system features zinc-plated steel mesh panels paired with hot-dip galvanised steel posts. Panels are 2.7 m high, topped with 300 mm anti-climb barbed wire, and coated with UV-stable powder for corrosion protection. Modular design enables rapid installation and future panel replacement. Earthing lugs ensure proper integration with substation grounding, maintaining electrical safety while enhancing security.

Product Attributes

• Material: Zinc-plated steel panels, hot-dip galvanised steel posts

• Panel Size: 2.7 m high × 2.4 m wide (pre-assembled modules)

• Topping: 300 mm barbed wire for anti-climb deterrence

• Mesh Infill: 8 mm welded wire, 100 × 50 mm rectangular openings

• Finish: UV-stable powder coat RAL 7016 (anthracite)

• Mounting: Posts embedded 800 mm into concrete; panels bolted with stainless fasteners

• Earthing: Integrated lugs, bonded to station grounding grid per IEEE Std 80

• Durability: Designed for coastal and remote exposure; corrosion-resistant over 20+ years

• Maintenance: Minimal, eliminates frequent repainting and repair cycles

• Standards Compliance: ASTM FENCE21, IEEE Std 80-2000, ISO 9001, ASCE

• Applications: Remote transformer stations, substations, utility sites

• Benefits: Asset protection, reduced maintenance costs, improved insurance terms, long service life
