Prototype-Ready Perforated Metal Grille Panels are designed for local fabrication environments, enabling R&D teams to rapidly test ventilation, airflow, and acoustic performance in prototype enclosures. Modular design supports iterative hole patterns and backing variations to optimize performance before full-scale production.

Product Description

These panels are built from 1.5 mm mild steel sheets with 4 mm holes at 10 mm pitch (~22% open area), allowing rapid customization and airflow testing. Modular frames and interchangeable acoustic backing enable multiple prototype iterations. The panels are CNC/laser compatible for in-house fabrication and fully documented for smooth transition to production. Ideal for acoustic enclosures, equipment racks, and ventilation systems requiring pre-production validation.

Product Attributes

• Material: Mild steel sheet, 1.5 mm thickness

• Perforation: 4 mm diameter, 10 mm pitch (~22% open area), custom pattern-ready

• Backing & Mounting: Modular frames with acoustic liner options for testing

• Fabrication Compatibility: CNC punch, laser-cut, local machine shop ready

• Prototype Iteration: Supports rapid design cycles and hole pattern modifications

• Performance Tested: Airflow within ±3% target; noise reduction improved by ~4 dB

• Application: Acoustic enclosures, vent panels, R&D prototypes, equipment racks

• Benefits: Rapid testing, local fabrication, modularity, production-ready documentation
