Disc Diameter: Customizable from 50mm to 500mm
Hole Diameter: 1.0mm to 5.0mm
Open Area Ratio: 20%–70%
Pattern Geometry: Straight, staggered, radial
Material Options: Stainless steel, aluminum, brass
Thickness: 0.5mm to 3mm
Manufacturing: CNC punching, laser cutting, waterjet
Pressure Drop Range: Configurable via pattern
Use Cases: CFD validation, wind tunnel studies, HVAC benchmarking
Mounting: Compatible with ducts, circular housings, or clamps
Surface Finish: Polished, matte, brushed
Edge Finish: Deburred, laser-smooth
Temperature Resistance: Up to 600°C
Corrosion Resistance: High (for stainless steel)
Measurement Tools: Compatible with hot-wire anemometry, PIV
Applications: University labs, aerospace R&D, filter benchmarking
Standard Compliance: ISO 9001, ASHRAE, ASTM airflow standards
Repeatability:<3% deviation across tests
Flow Type Support: Laminar, transitional, turbulent
Reynolds Number Range: Configurable via geometry
Mounting Options: Screw-lock, magnetic, press-fit
Documentation: CAD drawings, pressure-flow charts included
Customization: Pattern, diameter, shape available
Smart Integration: Ready for sensor feedback setups
Coating Options: Anodized, powder-coated, untreated
Anti-Vibration Options: Available on request
Pattern Simulation: CFD data available
Analytical Models: Ergun & Forchheimer compatibility
Lab Proven: Used in PIV & turbulence research
Field Tested: Wind tunnel & HVAC environments
Storage: Corrosion-resistant packaging
Availability: Made to order or standard SKUs
Lifecycle: Reusable across hundreds of tests
Maintenance: Wipe-clean or ultrasonic safe
Environmental Suitability: Indoor/outdoor use
Data Sheet: Provided upon request
Support: Engineering consultation available
