Product Description:
Jintong’s Metal Sunshade and Natural Vent Panels provide a passive cooling solution for rooftop HVAC units, data center backup generators, solar inverters, and industrial chillers. Designed to reduce direct solar gain while enabling natural airflow circulation, the system minimizes overheating, lowers maintenance, and improves equipment lifespan without any electrical input. Combining CFD-optimized perforated sunshade panels with convection-driven vent panels, this modular system transforms static rooftop equipment enclosures into energy-efficient, self-ventilating microclimates.

Product Attributes:

• Material: Anodized AA5052 Aluminium

• Panel Coating: Dual-layer nano-ceramic for UV, corrosion, and dust resistance

• Panel Thickness: 2–3 mm (custom per application)

• Sunshade Perforation: 35% open area, 30° pitch orientation for solar deflection

• Vent Panel Design: Sidewall natural venting, 12–20 mm slot width, buoyancy-driven airflow

• Air Gap: Adjustable 40–70 mm for convection management

• Installation: Modular, non-penetrative clip-on brackets

• Durability: Wind tested up to 22 m/s; vibration-resistant fasteners and gaskets

• Performance: Internal temperature reduction 17–22°C; surface reflectivity +24%; energy savings up to 15% for rooftop HVAC

• Maintenance: Filtered corridors, washable and reusable; biannual inspection recommended

• Applications: Industrial rooftops, hospital cooling systems, airport HVAC, off-grid renewable plants, container refrigeration decks
