This coastal fence system uses 2 mm steel sheet mesh panels with 8 mm welded wire infill, mounted on Ø 89 mm heavy-duty hot-dip galvanized posts embedded in concrete. Duplex coating (galvanising + polyester powder coat) ensures long-term corrosion resistance. Panels are modular for rapid installation and maintenance access. Integrated earthing aligns with IEEE Std 80‑2000 for safe grounding of the perimeter. The system meets ISO 9001 quality standards and ASCE structural guidelines.

Product Attributes

• Material: Carbon steel sheet mesh, hot-dip galvanized

• Panel Thickness: 2 mm; Mesh infill 8 mm

• Panel Size: 2.5 m wide × 2.8 m high modules

• Posts: Ø 89 mm steel tube, hot-dip galvanised, embedded 900 mm

• Finish: Duplex system (galvanising + powder coat RAL 7012)

• Earthing: Bonded to station grid per IEEE Std 80‑2000

• Modularity: Pre-assembled panels for fast installation and replacement

• Durability: Coastal-grade corrosion resistance, tested <0.5 mm zinc loss in 12 months

• Security: Resists unauthorized vehicle access and intrusion

• Compliance & Standards: ISO 9001, ASTM F2611‑08, ASCE structural, ASA acoustic guidance

• Applications: Coastal transformer stations, substations, high-voltage yard security, utility perimeter protection

• Maintenance Savings: 60% reduction in annual maintenance cost; extended service life

• Additional Benefits: Insurance premium reduction, improved operational safety
