This urban boundary fencing system uses carbon steel panels hot-dip galvanized per ASTM A123/A123M and optionally powder-coated for added protection and aesthetics. Panels are secured with tamper-resistant stainless steel screws, enabling modular assembly without welding. The design allows easy sectional replacement, reducing maintenance costs and downtime. The fence withstands urban pollutants, pedestrian and vehicle impact, and environmental exposure while maintaining long-term structural integrity and visual consistency.

Product Attributes

• Material: Carbon steel, hot-dip galvanized (ASTM A123/A123M compliant)

• Panel Size: 2.4 m high × 3.0 m wide

• Panel Thickness: Rails 40×40 mm, wall 2.0 mm; Posts 80×80 mm, wall 3.0 mm

• Fixings: Tamper-resistant stainless steel screws, zinc-plated, DIN-threaded

• Finish: Zinc coating + optional polyester powder coat for aesthetics and protection

• Modularity: Panels can be replaced individually without welding

• Durability: Corrosion-resistant for urban outdoor exposure

• Maintenance: Minimal; sectional replacement enabled by screw fixings

• Applications: Urban boundary renewal, redevelopment sites, industrial perimeters, mixed-use sites

• Compliance & Standards: ASTM A123/A123M, ASTM E477, ISO 9223, ASCE structural durability guidelines
